BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine
Item No. ADL002609
Reviews: 5 stars, 0 reviews
Brand:Alan Dental
- Special Offer in Blackfriday:
- 6% Off On Total Order Amount!
- Enjoy Discount at Checkout! No Need Coupon Code!
Market price:$3628.99
But It Now : $2198.99
Voltage :

Plug :

Quantity :
Weight:0gram
Goods click count:1206

Item Description Reviews

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine

Note: The PC table is optional, not included

Features:

* High-frequency design makes unit portable and compact, saving you space!

* 50/60Hz X-ray machine allows you to precisely control exposure time and repitition, providing consistent, customized images.

* Simple internal structure makes for easy operation and maintenance

* Delivers fast response speeds and highly-accuracy output indexes

* Adjustable KV (revolutions per minute of engine) and MA

* Can be powered directly from regular DC outlet (Unlike other Large-scale 50/60Hz X-line machines, which usually require special electrical wiring)

* Features a Toshiba 0.3x0.3 micro-focus spherical kinescope, ensuring crystal-clear images

* Uses 30mm×40mm Kodak film

* Can be controlled from the mainframe, head tube, or remote control (included)

Technical Specification :

a) The rated parameters of x-ray production device

1. Tube voltage: 70kv (fixed)

2.Tube current: 2MA (fixed)

3. High voltage generating circuit: High frequency switch

4. X-ray control method: Microprocessor control

5. Time setting range: 0.1-1.8 seconds

b) Weight: 2.5kg

c) Size: 215*140*160 mm

d) X-ray tubing

1. Type: bipolar fixed x-ray tube

2. X-ray tube Model: DG-073B-DC

3. The size of x-ray tube focal spot: 0.3*0.3mm

4. ANODE heating unit: 8.5Khu

5. Maximum tube voltage: 75Kv

6. Target angle: 21°

7. Total filtration: 1.6mmAL (Origin filtration: 0.8mmAL, Additional filtration: 1mmAL)

X-ray irradiation range: 73mm (roundness)

e) Useage voltage: battery DC16.8V

f) Charger: Input AC100-240V, Output: DC16.8V

Note: The PC table is optional, not included

Contact Information:
Live Support: Chat with us online
Email: service.alandental@gmail.com
If you have any problem, please do not hesitate to contact us.

Shipment Note:
If your package shipped by Express Delivery, please give us a valid delivery phone number, and also a full and accurate shipping address.
