BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine
  • BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine

  • Item No. ADL002609
  • Reviews: 5 stars, 0 reviews
  • Brand:Alan Dental
    • Special Offer in Blackfriday:
    • 6% Off On Total Order Amount!
    • Enjoy Discount at Checkout! No Need Coupon Code!
  • Market price:$3628.99
    But It Now : $2198.99
    Voltage :
    Plug :
    Quantity :

  • Weight:0gram
  • Goods click count:1206
Item Description Reviews

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine


Note: The PC table is optional, not included

Features:
* High-frequency design makes unit portable and compact, saving you space!
* 50/60Hz X-ray machine allows you to precisely control exposure time and repitition, providing consistent, customized images.
* Simple internal structure makes for easy operation and maintenance
* Delivers fast response speeds and highly-accuracy output indexes
* Adjustable KV (revolutions per minute of engine) and MA
* Can be powered directly from regular DC outlet (Unlike other Large-scale 50/60Hz X-line machines, which usually require special electrical wiring)
* Features a Toshiba 0.3x0.3 micro-focus spherical kinescope, ensuring crystal-clear images
* Uses 30mm×40mm Kodak film
* Can be controlled from the mainframe, head tube, or remote control (included)

Technical Specification :
a) The rated parameters of x-ray production device
1. Tube voltage: 70kv (fixed)
2.Tube current: 2MA (fixed)
3. High voltage generating circuit: High frequency switch
4. X-ray control method: Microprocessor control
5. Time setting range: 0.1-1.8 seconds

b)  Weight: 2.5kg
c)    Size: 215*140*160 mm

d)    X-ray tubing
1. Type: bipolar fixed x-ray tube
2. X-ray tube Model: DG-073B-DC
3. The size of x-ray tube focal spot: 0.3*0.3mm
4. ANODE heating unit: 8.5Khu
5. Maximum tube voltage: 75Kv
6. Target angle: 21°
7. Total filtration: 1.6mmAL (Origin filtration: 0.8mmAL, Additional filtration: 1mmAL)
X-ray irradiation range: 73mm (roundness)

e) Useage voltage: battery DC16.8V
f) Charger: Input AC100-240V, Output: DC16.8V

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine
Note: The PC table is optional, not included
Note: The PC table is optional, not included
Note: The PC table is optional, not included

BLX-10 Plus Portable X Ray Unit Dental Handheld X Ray Machine
